Pair of Test Panel Nickel 10-20-30-50 Micron
A set of two panels made by plating a brass panel first with brittle nickel, then with chrome.
About the Pair of Test Panel Nickel 10-20-30-50 Micron
A set of two panels made by plating a brass panel first with brittle nickel, then with chrome. The panels are approx. 1.5” (36 mm) in width and 4” (101 mm) in length, are machined from the same stock and have corresponding cracks. They are particularly effective in assessing the penetrant inspection system’s ability to detect surface discontinuities. It results to be very handy for simultaneous comparison of the penetrants from two batches. Sold in sets of two, with photographs. In compliance with: ISO 3452-3 TYPE 1; ASTM E1417; AMS 2647D; JIS Z 2343-3
Technical data
- Part Number 04099810: Pair of NiCr − 10μ Test Panel
- Ref.: 98.6/1
- Part Number 04099811: Pair of NiCr − 20μ Test Panel
- Ref.: 98.6/2
- Part Number 04099812: Pair of NiCr − 30μ Test Panel
- Ref.: 98.6/3
- Part Number 04099813: Pair of NiCr − 50μ Test Panel
- Ref.: 98.6/4
Values as published by CGM Cigiemme. Refer to the current technical datasheet for full conditions.
