Flavor Capsule High-Speed Automatic Optical Inspection Machine
The machine is specially used for inspection the appearance defects of Flavor capsule.
About the Flavor Capsule High-Speed Automatic Optical Inspection Machine
The machine is specially used for inspection the appearance defects of Flavor capsule. Common defects include bubbles, empty capsules, solid capsule, spots, deformed, color mixture, black spots, incomplete roundness, tailing, etc. It supports automatic feeding, image processing and NG capsule sorting.
Documented functions: defect detection, classification & sorting. Defect types, inspection ranges, speeds and optical resolution in the specification table are quoted from K2 TECH; optical resolution describes the imaging system and is not a measurement accuracy unless stated as such.
Final detection capability depends on part condition, presentation, cycle time and the agreed defect catalogue; EMUS validates these with K2 TECH using sample parts before quotation.
- New Rotation MechanismA new rotation mechanism has been added to enable 360-degree comprehensive inspection. In addition, the industrial touchscreen interface provides easy operation, reducing the need for extensive operator training.
- Multi-channel Parallel DetectionThe equipment adopts multi-channel parallel detection, effectively improving inspection speed with the rate as of 800,000 pcs/h
- Mechanical Sorting FunctionMechanical sorting function can be extended to prevent the deformation capsule from disturbing the afterwards procedure. It can also achieve 7*24 hours of continuous inspection.
Technical data
- Inspection Item
- Bubbles, empty capsules, solid capsule, spots, deformed, color mixture, black spots, incomplete roundness, tailing, etc
- Inspection Range
- Ф 2-4mm
- Optical Resolution
- 0.03mm
- Inspection Precision
- 0.3mm
- Mean Time Between Failures
- 10,000H
- Speed
- 800,000pcs/h
- Power
- 2000 W
- Voltage
- 220V, 50HZ
- Air Pressure
- 0.5～0.8MPa
- Size/Weight
- 1.8 m*0.8 m*1.6 m / 300kg
- Working Environment
- 5℃-30℃；Humidity<70%
- Features
- 1. The size of dripping pills was counted in real time and displayed intuitively with the normal distribution map.2. The device real-time display detection status and NG number alarm.3. The software has remote technical support capabilities.
Data from official K2 TECH product information. Final configuration is confirmed in the EMUS quotation.
Product imagery
Official product videos
Brochures, datasheets & catalogues
AOI machines for medical & food (capsules) — catalogue (2024-11)
PDF · Catalogue
