Guide Tubes
Articulating and non-articulating guide tubes with working channels for videoscopes, fiberscopes and retrieval tools.
About the Guide Tubes
Guide tubes reach areas that are difficult to access with endoscopes, for example in turbine testing. Articulating guide tubes (Ø 19–22 mm) have an integrated working channel of 6.3–9 mm through which flexible endoscopes, videoscopes and retrieval tools are guided, with 4 × 110° or 4 × 90° articulation. Rigid, semi-rigid and flexible non-articulating guide tubes (Ø 5.5–14 mm, channel 3.7–8.4 mm) stabilise flexible probes, bridge gaps and protect endoscopes from sharp edges.
- Articulating guide tubes with working channel
- Rigid, semi-rigid and flexible versions
- Guide videoscopes, fiberscopes and retrieval tools
- Protect probes from sharp edges
Technical data
- Diameter
- 19 – 22 mm
- Working channel
- 6.3 – 9 mm
- Articulation
- 4 × 110° / 4 × 90°
- Diameter
- 5.5 – 14 mm
- Working channel
- 3.7 – 8.4 mm
- Construction
- Rigid / semi-rigid / flexible
Data from official viZaar product information. Final configuration is confirmed in the EMUS quotation.
Product imagery
Brochures & catalogues
Retrieval tools & guide tubes — Catalogue
PDF ·Catalogue
