4680 Battery Vision Inspection Machine
Suitable for the detection and packaging of 4680 cylindrical lithium battery, the equipment is mainly used for automatic feeding of cylindrical lithium batteries, coding, electrostatic dust removal, appearance detection (positive electrode，negative electrode a
About the 4680 Battery Vision Inspection Machine
Suitable for the detection and packaging of 4680 cylindrical lithium battery, the equipment is mainly used for automatic feeding of cylindrical lithium batteries, coding, electrostatic dust removal, appearance detection (positive electrode，negative electrode and shell), battery scanning, automatic packaging, CCD review, carton labeling, bar code binding, automatic packaging and other processes.
Documented functions: defect detection, handling, packaging & line integration. Defect types, inspection ranges, speeds and optical resolution in the specification table are quoted from K2 TECH; optical resolution describes the imaging system and is not a measurement accuracy unless stated as such.
Final detection capability depends on part condition, presentation, cycle time and the agreed defect catalogue; EMUS validates these with K2 TECH using sample parts before quotation.
- High-Precision Vision Inspection SystemUtilizing industrial-grade high-resolution cameras with multi-angle lighting systems to ensure 360° defect detection without blind spots.
- AI-Powered Defect RecognitionBy using deep learning algorithms to automatically identify surface defects,features adaptive learning capability to continuously optimize inspection criteria,supports multi-category defect classification and statistical analysis.
- Full automatic PackagingIncluding automatic alignment, counting, and grouping functions,offers multiple packaging options (trays, blister boxes, reels, etc.),integrates automatic labeling, inkjet printing, and data association
Technical data
- Inspection Item
- Defects such as indentation, nicks, foreign matter, contamination, corrosion and so on in the polar and raceway surface of lithium battery
- Inspection Range
- 4680 Battery
- Missing Rate
- 0%
- Optical Resolution
- 0.02mm
- Precision
- 0.1mm
- Speed
- 60PPM
- Voltage
- 220V,50HZ
- Power
- 14KW
- Air Pressure
- 0.5 MPa～0.8MPa
- Size/Weight
- 12000(L)*2500(W)*2000(H)mm/5000Kg
- Working Environment
- 5℃-30℃；Humidity<70%
- Other Features
- 1. Real-time display of detection status and NG quantity alarm; 2. The equipment software has remote technical support function; 3. The packaging line can be extended; 4. The structure is more simple, support one-key transformation; 5. Extensible scanning code system.
Data from official K2 TECH product information. Final configuration is confirmed in the EMUS quotation.
Product imagery
Official product videos
Brochures, datasheets & catalogues
Cylindrical lithium battery vision inspection & packing line — brochure (2025)
PDF · Brochure
